ATAK - Android TAK

Product available:​

https://tak.gov/products/atak-civ

https://play.google.com/store/apps/details?id=com.atakmap.app.civ

Product manual​

ATAK 5.5 User Guide.pdf 4198740

ATAK 5.6 User Guide.pdf 4168380

Product Description​

The Android Team Awareness Kit (ATAK-CIV) offers matching capabilities to the ATAK-MIL baseline with minor changes from the military lexicon. TAK-CIV is made available to support the principles of civil authority emergency operations: prevention, mitigation, preparation, response, or emergency evacuation and recovery. The primary difference between MIL & CIV is the baseline signing key that restricts military specific capability from being loaded through plugins. Just like ATAK-MIL, ATAK-CIV is network-agnostic and works with many tactical communication systems. ATAK-CIV supports DoD and commercial formatted maps, imagery, and overlays. Where possible, the ATAK application adheres to the user experience design guidelines produced by Google to ensure that end users have a familiar experience.

System Requirements​

ATAK System Requirements

  • Operating System: ATAK requires Android 5.0 (API 21) or later.
  • Hardware: ATAK does not require specific hardware and should run on any Android device that supports the other System Requirements.
  • Graphics: ATAK requires a graphics processor that supports GLES 3.0.
  • Storage, Memory and Processor: ATAK does not have any specific requirements for storage, memory or processor, however, performance of the application will depend on the configuration.
  • Examples of Devices: Testing of TAK is generally done across a range of Samsung devices since they are primarily what has been fielded. That being said, TAK works on other non-Samsung devices. For a small phone style device the Samsung S5 equivalent hardware or newer is required and for a tablet style device Samsung Tab S equivalent or newer. It is recommended: for optimal experience, at least a Samsung S9 equivalent hardware or newer is used and for a tablet style device Samsung S2 equivalent or newer.
